カスタム高速スイッチ
仕様
| High-Speed Switches | |
|---|---|
| Insertion Loss (dB) | < 3.0 (for 1x2 Switch) |
| Switching Time (ns) | << 100 |
| Cross Talk (dB) | < 20 (for PM) |
| Configurations | 1x2, 2x2, ..., 1x8, ... |
| Polarization | Independent or Maintaining |
| Optical Return Loss (dB) | > 45 |
| Wavelength (micron) | 1.55 (C-Band and L-Band) |
| Input Fiber | SM or PM |
| Output Fiber | SM or PM |
| Optical Connectors | FC/UPC Standard (FC/APC & Others) |
詳細
Options: Sub-Nanosecond Switching
Options: Crosstalk < 30 dB
Options: Arrays of 2x2 Switches
Options: Custom Configurations
Options: 1.06 & 1.3 mircon Operating Wavelength
