Voltage Controlled Oscillators

メーカー名:Eravant

製品仕様

Product Specifications

modelData sheetCenter Frequency [GHz]Output Power [dBm]Mechanical Tuning RangeFrequency Tuning Range [GHz]Bias [VDC/mA]Varactor Tuning Voltage Range [VDC]RF PortVaractor Tuning Port
SOW-11305316-SF-U2Datasheet10.5+16 Min--+12.0 / 3000 to +15SMA (F)SMA (F)
SOW-11305310-SM-U2Datasheet10.83+10--+8.0 / 1800.5 to +15.5SMA (M)SMA (F)
SOW-15303315-SM-S1-HDatasheet14.75+15-}1.75+8 / 200+0.2 to +13SMA (M)SMA (F)
SOW-17303315-SF-U2Datasheet16.5+15--+8.0 / 340-SMA (F)SMA (F)

備考

Remarks
