Standard WG Fixed Attenuators

メーカー名:Eravant

製品仕様

Product Specifications

Model NumberData sheetMinimum FrequencyMaximum FrequencyAttenuationReturn LossPower HandlingRF PortAttenuator Type
STA-10-06-F3Datasheet110 GHz170 GHz10 dB @ 140 GHz16 dB0.3 WWR-06 WaveguideFixed
STA-10-06-F1Datasheet110 GHz170 GHz10 dB @ 140 GHz20 dB300 mWWR-06 WaveguideFixed
STA-10-06-F2Datasheet110 GHz170 GHz10 dB @ 140 GHz16 dB0.50 WWR-06 WaveguideFixed
STA-20-06-F3Datasheet110 GHz170 GHz20 dB @ 140 GHz16 dB0.3 WWR-06 WaveguideFixed
STA-20-06-F1Datasheet110 GHz170 GHz20 dB @ 140 GHz20 dB300 mWWR-06 WaveguideFixed
STA-20-06-F2Datasheet110 GHz170 GHz20 dB @ 140 GHz16 dB0.50 WWR-06 WaveguideFixed
STA-03-06-F3Datasheet110 GHz170 GHz3 dB @ 140 GHz16 dB0.3 WWR-06 WaveguideFixed
STA-03-06-F1Datasheet110 GHz170 GHz3 dB @ 140 GHz20 dB300 mWWR-06 WaveguideFixed
STA-03-06-F2Datasheet110 GHz170 GHz3 dB @ 140 GHz16 dB0.50 WWR-06 WaveguideFixed
STA-30-06-F3Datasheet110 GHz170 GHz30 dB @ 140 GHz16 dB0.3 WWR-06 WaveguideFixed
STA-30-06-F1Datasheet110 GHz170 GHz30 dB @ 140 GHz20 dB300 mWWR-06 WaveguideFixed
STA-30-06-F2Datasheet110 GHz170 GHz30 dB @ 140 GHz0.30 WWR-06 WaveguideFixed
STA-06-06-F3Datasheet110 GHz170 GHz6 dB @ 140 GHz16 dB0.3 WWR-06 WaveguideFixed
STA-06-06-F1Datasheet110 GHz170 GHz6 dB @ 140 GHz20 dB300 mWWR-06 WaveguideFixed
STA-06-06-F2Datasheet110 GHz170 GHz6 dB @ 140 GHz16 dB0.50 WWR-06 WaveguideFixed
STA-10-05-F2Datasheet140 GHz220 GHz10 dB @ 180 GHz16 dB0.3 WWR-05 WaveguideFixed
STA-20-05-F2Datasheet140 GHz220 GHz20 dB @ 180 GHz16 dB0.3 WWR-05 WaveguideFixed
STA-03-05-F2Datasheet140 GHz220 GHz3 dB @ 180 GHz16 dB0.3 WWR-05 WaveguideFixed
STA-30-05-F2Datasheet140 GHz220 GHz30 dB @ 180 GHz16 dB0.3 WWR-05 WaveguideFixed
STA-06-05-F2Datasheet140 GHz220 GHz6 dB @ 180 GHz16 dB0.3 WWR-05 WaveguideFixed
STA-10-04-F2Datasheet170 GHz260 GHz10 dB @ 215 GHz16 dB0.3 WWR-04 WaveguideFixed
STA-20-04-F2Datasheet170 GHz260 GHz20 dB @ 215 GHz16 dB0.3 WWR-04 WaveguideFixed
STA-03-04-F2Datasheet170 GHz260 GHz3 dB @ 215 GHz16 dB0.3 WWR-04 WaveguideFixed
STA-30-04-F2Datasheet170 GHz260 GHz30 dB @ 215 GHz16 dB0.3 WWR-04 WaveguideFixed
STA-06-04-F2Datasheet170 GHz260 GHz6 dB @ 215 GHz16 dB0.3 WWR-04 WaveguideFixed
STA-10-42-F2Datasheet18 GHz26.5 GHz10 dB @ 22.25 GHz0.75 WWR-42 WaveguideFixed
STA-20-42-F2Datasheet18 GHz26.5 GHz20 dB @ 22.25 GHz0.75 WWR-42 WaveguideFixed
STA-03-42-F2Datasheet18 GHz26.5 GHz3 dB @ 22.25 GHz0.75 WWR-42 WaveguideFixed
STA-30-42-F2Datasheet18 GHz26.5 GHz30 dB @ 22.25 GHz0.75 WWR-42 WaveguideFixed
STA-40-42-F2Datasheet18 GHz26.5 GHz40 dB @ 22.25 GHz0.75 WWR-42 WaveguideFixed
STA-06-42-F2Datasheet18 GHz26.5 GHz6 dB @ 22.25 GHz0.75 WWR-42 WaveguideFixed
STA-03-42-F1Datasheet18 GHz26.5 GHz03 dB @ 22.25 GHz20 dB0.75 WWR-42 WaveguideFixed
STA-06-42-F1Datasheet18 GHz26.5 GHz06 dB @ 22.25 GHz20 dB0.75 WWR-42 WaveguideFixed
STA-10-42-F1Datasheet18 GHz26.5 GHz10 dB @ 22.25 GHz20 dB0.75 WWR-42 WaveguideFixed
STA-20-42-F1Datasheet18 GHz26.5 GHz20 dB @ 22.25 GHz20 dB0.75 WWR-42 WaveguideFixed
STA-30-42-F1Datasheet18 GHz26.5 GHz30 dB @ 22.25 GHz20 dB0.75 WWR-42 WaveguideFixed
STA-40-42-F1Datasheet18 GHz26.5 GHz40 dB @ 22.25 GHz20 dB0.75 WWR-42 WaveguideFixed
STA-50-42-F1Datasheet18 GHz26.5 GHz50 dB @ 22.25 GHz20 dB0.75 WWR-42 WaveguideFixed
STA-03-34-F1Datasheet22 GHz33 GHz03 dB @ 27.5 GHz20 dB0.75 WWR-34 WaveguideFixed
STA-06-34-F1Datasheet22 GHz33 GHz06 dB @ 27.5 GHz20 dB0.75 WWR-34 WaveguideFixed
STA-10-34-F1Datasheet22 GHz33 GHz10 dB @ 27.5 GHz20 dB0.75 WWR-34 WaveguideFixed
STA-10-34-F2Datasheet22 GHz33 GHz10 dB @ 27.5 GHz23 dB0.75 WWR-34 WaveguideFixed
STA-20-34-F1Datasheet22 GHz33 GHz20 dB @ 27.5 GHz20 dB0.75 WWR-34 WaveguideFixed
STA-20-34-F2Datasheet22 GHz33 GHz20 dB @ 27.5 GHz23 dB0.75 WWR-34 WaveguideFixed
STA-03-34-F2Datasheet22 GHz33 GHz3 dB @ 27.5 GHz23 dB0.75 WWR-34 WaveguideFixed
STA-30-34-F1Datasheet22 GHz33 GHz30 dB @ 27.5 GHz20 dB0.75 WWR-34 WaveguideFixed
STA-30-34-F2Datasheet22 GHz33 GHz30 dB @ 27.5 GHz23 dB0.75 WWR-34 WaveguideFixed
STA-40-34-F1Datasheet22 GHz33 GHz40 dB @ 27.5 GHz20 dB0.75 WWR-34 WaveguideFixed
STA-50-34-F1Datasheet22 GHz33 GHz50 dB @ 27.5 GHz20 dB0.75 WWR-34 WaveguideFixed
STA-06-34-F2Datasheet22 GHz33 GHz6 dB @ 27.5 GHz23 dB0.75 WWR-34 WaveguideFixed
STA-10-03-F2Datasheet220 GHz325 GHz10 dB @ 272.5 GHz16 dB0.3 WWR-03 WaveguideFixed
STA-20-03-F2Datasheet220 GHz325 GHz20 dB @ 272.5 GHz16 dB0.3 WWR-03 WaveguideFixed
STA-03-03-F2Datasheet220 GHz325 GHz3 dB @ 272.5 GHz16 dB0.3 WWR-03 WaveguideFixed
STA-30-03-F2Datasheet220 GHz325 GHz30 dB @ 272.5 GHz16 dB0.3 WWR-03 WaveguideFixed
STA-06-03-F2Datasheet220 GHz325 GHz6 dB @ 272.5 GHz16 dB0.3 WWR-03 WaveguideFixed
STA-10-28-F2Datasheet26.5 GHz40 GHz10 dB @ 32.25 GHz0.75 WWR-28 WaveguideFixed
STA-20-28-F2Datasheet26.5 GHz40 GHz20 dB @ 32.25 GHz0.75 WWR-28 WaveguideFixed
STA-03-28-F2Datasheet26.5 GHz40 GHz3 dB @ 32.25 GHz0.75 WWR-28 WaveguideFixed
STA-30-28-F2Datasheet26.5 GHz40 GHz30 dB @ 32.25 GHz0.75 WWR-28 WaveguideFixed
STA-40-28-F2Datasheet26.5 GHz40 GHz40 dB @ 33.25 GHz0.75 WWR-28 WaveguideFixed
STA-50-28-F2Datasheet26.5 GHz40 GHz50 dB @ 32.25 GHz0.75 WWR-28 WaveguideFixed
STA-06-28-F2Datasheet26.5 GHz40 GHz6 dB @ 32.25 GHz0.75 WWR-28 WaveguideFixed
STA-03-28-F1Datasheet26.5 GHz40 GHz03 dB @ 33.25 GHz20 dB0.75 WWR-28 WaveguideFixed
STA-06-28-F1Datasheet26.5 GHz40 GHz06 dB @ 33.25 GHz20 dB0.75 WWR-28 WaveguideFixed
STA-10-28-F1Datasheet26.5 GHz40 GHz10 dB @ 33.25 GHz20 dB0.75 WWR-28 WaveguideFixed
STA-20-28-F1Datasheet26.5 GHz40 GHz20 dB @ 33.25 GHz20 dB0.75 WWR-28 WaveguideFixed
STA-30-28-F1Datasheet26.5 GHz40 GHz30 dB @ 33.25 GHz20 dB0.75 WWR-28 WaveguideFixed
STA-40-28-F1Datasheet26.5 GHz40 GHz40 dB @ 33.25 GHz20 dB0.75 WWR-28 WaveguideFixed
STA-50-28-F1Datasheet26.5 GHz40 GHz50 dB @ 33.25 GHz20 dB0.75 WWR-28 WaveguideFixed
STA-10-22-F1Datasheet33 GHz50 GHz10 dB @ 41.5 GHz20 dB0.5 WWR-22 WaveguideFixed
STA-10-22-F2Datasheet33 GHz50 GHz10 dB @ 41.5 GHz21 dB500 mWWR-22 WaveguideFixed
STA-20-22-F1Datasheet33 GHz50 GHz20 dB @ 41.5 GHz20 dB0.5 WWR-22 WaveguideFixed
STA-20-22-F2Datasheet33 GHz50 GHz20 dB @ 41.5 GHz0.50 WWR-22 WaveguideFixed
STA-03-22-F1Datasheet33 GHz50 GHz3 dB @ 41.5 GHz20 dB0.5 WWR-22 WaveguideFixed
STA-03-22-F2Datasheet33 GHz50 GHz3 dB @ 41.5 GHz21 dB500 mWWR-22 WaveguideFixed
STA-30-22-F1Datasheet33 GHz50 GHz30 dB @ 41.5 GHz20 dB0.5 WWR-22 WaveguideFixed
STA-30-22-F2Datasheet33 GHz50 GHz30 dB @ 41.5 GHz21 dB500 mWWR-22 WaveguideFixed
STA-40-22-F1Datasheet33 GHz50 GHz40 dB @ 41.5 GHz20 dB0.5 WWR-22 WaveguideFixed
STA-40-22-F2Datasheet33 GHz50 GHz40 dB @ 41.5 GHz0.50 WWR-22 WaveguideFixed
STA-50-22-F1Datasheet33 GHz50 GHz50 dB @ 41.5 GHz20 dB0.5 WWR-22 WaveguideFixed
STA-50-22-F2Datasheet33 GHz50 GHz50 dB @ 41.5 GHz21 dB500 mWWR-22 WaveguideFixed
STA-06-22-F1Datasheet33 GHz50 GHz6 dB @ 41.5 GHz20 dB0.5 WWR-22 WaveguideFixed
STA-06-22-F2Datasheet33 GHz50 GHz6 dB @ 41.5 GHz21 dB500 mWWR-22 WaveguideFixed
STA-10-19-F1Datasheet40 GHz60 GHz10 dB @ 50 GHz20 dB0.5 WWR-19 WaveguideFixed
STA-10-19-F2Datasheet40 GHz60 GHz10 dB @ 50 GHz21 dB500 mWWR-19 WaveguideFixed
STA-20-19-F1Datasheet40 GHz60 GHz20 dB @ 50 GHz20 dB0.5 WWR-19 WaveguideFixed
STA-20-19-F2Datasheet40 GHz60 GHz20 dB @ 50 GHz21 dB500 mWWR-19 WaveguideFixed
STA-03-19-F1Datasheet40 GHz60 GHz3 dB @ 50 GHz20 dB0.5 WWR-19 WaveguideFixed
STA-03-19-F2Datasheet40 GHz60 GHz3 dB @ 50 GHz21 dB500 mWWR-19 WaveguideFixed
STA-30-19-F1Datasheet40 GHz60 GHz30 dB @ 50 GHz20 dB0.5 WWR-19 WaveguideFixed
STA-30-19-F2Datasheet40 GHz60 GHz30 dB @ 50 GHz21 dB500 mWWR-19 WaveguideFixed
STA-40-19-F1Datasheet40 GHz60 GHz40 dB @ 50 GHz20 dB0.5 WWR-19 WaveguideFixed
STA-40-19-F2Datasheet40 GHz60 GHz40 dB @ 50 GHz0.50 WWR-19 WaveguideFixed
STA-50-19-F1Datasheet40 GHz60 GHz50 dB @ 50 GHz20 dB0.5 WWR-19 WaveguideFixed
STA-50-19-F2Datasheet40 GHz60 GHz50 dB @ 50 GHz0.50 WWR-19 WaveguideFixed
STA-06-19-F1Datasheet40 GHz60 GHz6 dB @ 50 GHz20 dB0.5 WWR-19 WaveguideFixed
STA-06-19-F2Datasheet40 GHz60 GHz6 dB @ 50 GHz21 dB500 mWWR-19 WaveguideFixed
STA-10-15-F1Datasheet50 GHz75 GHz10 dB @ 62.5 GHz20 dB0.5 WWR-15 WaveguideFixed
STA-10-15-F2Datasheet50 GHz75 GHz10 dB @ 62.5 GHz0.50 WWR-15 WaveguideFixed
STA-20-15-F1Datasheet50 GHz75 GHz20 dB @ 62.5 GHz20 dB0.5 WWR-15 WaveguideFixed
STA-20-15-F2Datasheet50 GHz75 GHz20 dB @ 62.5 GHz0.50 WWR-15 WaveguideFixed
STA-03-15-F1Datasheet50 GHz75 GHz3 dB @ 62.5 GHz20 dB0.5 WWR-15 WaveguideFixed
STA-30-15-F1Datasheet50 GHz75 GHz30 dB @ 62.5 GHz20 dB0.5 WWR-15 WaveguideFixed
STA-30-15-F2Datasheet50 GHz75 GHz30 dB @ 62.5 GHz0.50 WWR-15 WaveguideFixed
STA-40-15-F1Datasheet50 GHz75 GHz40 dB @ 62.5 GHz20 dB0.5 WWR-15 WaveguideFixed
STA-50-15-F1Datasheet50 GHz75 GHz50 dB @ 62.5 GHz20 dB0.5 WWR-15 WaveguideFixed
STA-50-15-F2Datasheet50 GHz75 GHz50 dB @ 62.5 GHz0.50 WWR-15 WaveguideFixed
STA-06-15-F1Datasheet50 GHz75 GHz6 dB @ 62.5 GHz20 dB0.5 WWR-15 WaveguideFixed
STA-06-15-F2Datasheet50 GHz75 GHz6 dB @ 62.5 GHz0.50 WWR-15 WaveguideFixed
STA-10-12-F1Datasheet60 GHz90 GHz10 dB @ 75 GHz20 dB0.5 WWR-12 WaveguideFixed
STA-10-12-F2Datasheet60 GHz90 GHz10 dB @ 75 GHz0.50 WWR-12 WaveguideFixed
STA-20-12-F1Datasheet60 GHz90 GHz20 dB @ 75 GHz20 dB0.5 WWR-12 WaveguideFixed
STA-20-12-F2Datasheet60 GHz90 GHz20 dB @ 75 GHz0.50 WWR-12 WaveguideFixed
STA-03-12-F1Datasheet60 GHz90 GHz3 dB @ 75 GHz20 dB0.5 WWR-12 WaveguideFixed
STA-30-12-F1Datasheet60 GHz90 GHz30 dB @ 75 GHz20 dB0.5 WWR-12 WaveguideFixed
STA-30-12-F2Datasheet60 GHz90 GHz30 dB @ 75 GHz0.50 WWR-12 WaveguideFixed
STA-40-12-F1Datasheet60 GHz90 GHz40 dB @ 75 GHz20 dB0.5 WWR-12 WaveguideFixed
STA-40-12-F2Datasheet60 GHz90 GHz40 dB @ 75 GHz21 dB500 mWWR-12 WaveguideFixed
STA-50-12-F1Datasheet60 GHz90 GHz50 dB @ 75 GHz20 dB0.5 WWR-12 WaveguideFixed
STA-50-12-F2Datasheet60 GHz90 GHz50 dB @ 75 GHz21 dB500 mWWR-12 WaveguideFixed
STA-06-12-F1Datasheet60 GHz90 GHz6 dB @ 75 GHz20 dB0.5 WWR-12 WaveguideFixed
STA-06-12-F2Datasheet60 GHz90 GHz6 dB @ 75 GHz0.50 WWR-12 WaveguideFixed
STA-10-10-F1Datasheet75 GHz110 GHz10 dB @ 92.5 GHz20 dB0.5 WWR-10 WaveguideFixed
STA-20-10-F1Datasheet75 GHz110 GHz20 dB @ 92.5 GHz20 dB0.5 WWR-10 WaveguideFixed
STA-20-10-F2Datasheet75 GHz110 GHz20 dB @ 92.5 GHz0.50 WWR-10 WaveguideFixed
STA-03-10-F1Datasheet75 GHz110 GHz3 dB @ 92.5 GHz20 dB0.5 WWR-10 WaveguideFixed
STA-03-10-F2Datasheet75 GHz110 GHz3 dB @ 92.5 GHz0.50 WWR-10 WaveguideFixed
STA-30-10-F1Datasheet75 GHz110 GHz30 dB @ 92.5 GHz20 dB0.5 WWR-10 WaveguideFixed
STA-30-10-F2Datasheet75 GHz110 GHz30 dB @ 92.5 GHz0.50 WWR-10 WaveguideFixed
STA-40-10-F1Datasheet75 GHz110 GHz40 dB @ 92.5 GHz20 dB0.5 WWR-10 WaveguideFixed
STA-50-10-F1Datasheet75 GHz110 GHz50 dB @ 92.5 GHz20 dB0.5 WWR-10 WaveguideFixed
STA-06-10-F1Datasheet75 GHz110 GHz6 dB @ 92.5 GHz20 dB0.5 WWR-10 WaveguideFixed
STA-10-08-F3Datasheet90 GHz140 GHz10 dB @ 115 GHz16 dB0.3 WWR-08 WaveguideFixed
STA-10-08-F1Datasheet90 GHz140 GHz10 dB @ 115 GHz20 dB300 mWWR-08 WaveguideFixed
STA-10-08-F2Datasheet90 GHz140 GHz10 dB @ 115 GHz16 dB0.50 WWR-08 WaveguideFixed
STA-20-08-F3Datasheet90 GHz140 GHz20 dB @ 115 GHz16 dB0.3 WWR-08 WaveguideFixed
STA-20-08-F1Datasheet90 GHz140 GHz20 dB @ 115 GHz20 dB300 mWWR-08 WaveguideFixed
STA-20-08-F2Datasheet90 GHz140 GHz20 dB @ 115 GHz16 dB0.50 WWR-08 WaveguideFixed
STA-03-08-F3Datasheet90 GHz140 GHz3 dB @ 115 GHz16 dB0.3 WWR-08 WaveguideFixed
STA-03-08-F1Datasheet90 GHz140 GHz3 dB @ 115 GHz20 dB300 mWWR-08 WaveguideFixed
STA-03-08-F2Datasheet90 GHz140 GHz3 dB @ 115 GHz16 dB0.50 WWR-08 WaveguideFixed
STA-30-08-F3Datasheet90 GHz140 GHz30 dB @ 115 GHz16 dB0.3 WWR-08 WaveguideFixed
STA-30-08-F1Datasheet90 GHz140 GHz30 dB @ 115 GHz20 dB300 mWWR-08 WaveguideFixed
STA-30-08-F2Datasheet90 GHz140 GHz30 dB @ 115 GHz16 dB0.50 WWR-08 WaveguideFixed
STA-06-08-F3Datasheet90 GHz140 GHz6 dB @ 115 GHz16 dB0.3 WWR-08 WaveguideFixed
STA-06-08-F1Datasheet90 GHz140 GHz6 dB @ 115 GHz20 dB300 mWWR-08 WaveguideFixed
STA-06-08-F2Datasheet90 GHz140 GHz6 dB @ 115 GHz16 dB0.50 WWR-08 WaveguideFixed
