Spectrum Analyzer Harmonic Mixers

メーカー名:Eravant

製品仕様

Product Specifications

Model NumberData sheetMinimum FrequencyMaximum FrequencyIF Minimum FrequencyIF Maximum FrequencyLO PowerRF Input PowerRF PortIF and LO Ports
STH-06SF-S1Datasheet110 GHz170 GHzDC4 GHz+13 dBm-20 dBmWR-06 WaveguideSMA (F)
STH-42SF-S1Datasheet18 GHz26.5 GHzDC4 GHz+13 dBm-20 dBmWR-42 WaveguideSMA (F)
STH-28SF-S1Datasheet26.5 GHz40 GHzDC4 GHz+13 dBm-20 dBmWR-28 WaveguideSMA (F)
STH-22SF-S1Datasheet33 GHz50 GHzDC4 GHz+13 dBm-20 dBmWR-22 WaveguideSMA (F)
STH-19SF-S1Datasheet40 GHz60 GHzDC4 GHz+13 dBm-20 dBmWR-19 WaveguideSMA (F)
STH-15SF-S1Datasheet50 GHz75 GHzDC4 GHz+13 dBm-20 dBmWR-15 WaveguideSMA (F)
STH-12SF-S1Datasheet60 GHz90 GHzDC4 GHz+13 dBm-20 dBmWR-12 WaveguideSMA (F)
STH-10SF-S1Datasheet75 GHz110 GHzDC4 GHz+13 dBm-20 dBmWR-10 WaveguideSMA (F)
STH-08SF-S1Datasheet90 GHz140 GHzDC4 GHz+13 dBm-20 dBmWR-08 WaveguideSMA (F)

備考

Remarks
