Semi-Rigid Coaxial Cable Assemblies

メーカー名:Eravant

製品仕様

Product Specifications

ModelData sheetMinimum FrequencyMaximum Frequency [GHz]Return Loss [dB]Impedance [Ohms]Cable LengthCable TypeCable Outer DiameterMinimum Bending RadiusConnectors
SCW-1M1M003-S1DatasheetDC11013503"Semi-Rigid0.047"0.126"1 mm Male
SCW-1M1M006-S1DatasheetDC11013506"Semi-Rigid0.047"0.126"1 mm Male
SCW-1M1M012-S1DatasheetDC110135012"Semi-Rigid0.047"0.126"1 mm Male
SCW-VMVM003-S1DatasheetDC6016503"Semi-Rigid0.087"0.126"V(M)
SCW-VMVM003-S1-PMDatasheetDC6016503"Semi-Rigid0.087"0.126"V(M)
SCW-VMVM006-S1DatasheetDC6016506"Semi-Rigid0.087"0.126"V(M)
SCW-VMVM006-S1-PMDatasheetDC6016506"Semi-Rigid0.087"0.126"V(M)
SCW-VMVM012-S1DatasheetDC60165012"Semi-Rigid0.087"0.126"V(M)
SCW-VMVM012-S1-PMDatasheetDC60165012"Semi-Rigid0.087"0.126"V(M)
SCW-VMVM024-S1DatasheetDC60165024"Semi-Rigid0.087"0.126"V(M)
SCW-VMVM024-S1-PMDatasheetDC60165024"Semi-Rigid0.087"0.126"V(M)
SCW-VMVM040-S1DatasheetDC60165040"Semi-Rigid0.087"0.126"V(M)
SCW-VMVM040-S1-PMDatasheetDC60165040"Semi-Rigid0.087"0.126"V(M)
SCW-VMVM048-S1DatasheetDC60165048"Semi-Rigid0.087"0.126"V(M)
SCW-VMVM048-S1-PMDatasheetDC60165048"Semi-Rigid0.087"0.126"V(M)
SCW-VMVM060-S1DatasheetDC60165060"Semi-Rigid0.087"0.126"V(M)
SCW-VMVM060-S1-PMDatasheetDC60165060"Semi-Rigid0.087"0.126"V(M)
SCW-2M2M003-S1DatasheetDC5017503"Semi-Rigid0.087"0.126"2.4 mm (M)
SCW-2M2M003-S1-PMDatasheetDC5017503"Semi-Rigid0.087"0.126"2.4 mm (M)
SCW-2M2M006-S1DatasheetDC5017506"Semi-Rigid0.087"0.126"2.4 mm (M)
SCW-2M2M006-S1-PMDatasheetDC5017506"Semi-Rigid0.087"0.126"2.4 mm (M)
SCW-2M2M012-S1DatasheetDC50175012"Semi-Rigid0.087"0.126"2.4 mm (M)
SCW-2M2M012-S1-PMDatasheetDC50175012"Semi-Rigid0.087"0.126"2.4 mm (M)
SCW-2M2M024-S1DatasheetDC50175024"Semi-Rigid0.087"0.126"2.4 mm (M)
SCW-2M2M024-S1-PMDatasheetDC50175024"Semi-Rigid0.087"0.126"2.4 mm (M)
SCW-2M2M040-S1DatasheetDC50175040"Semi-Rigid0.087"0.126"2.4 mm (M)
SCW-2M2M040-S1-PMDatasheetDC50175040"Semi-Rigid0.087"0.126"2.4 mm (M)
SCW-2M2M048-S1DatasheetDC50175048"Semi-Rigid0.087"0.126"2.4 mm (M)
SCW-2M2M048-S1-PMDatasheetDC50175048"Semi-Rigid0.087"0.126"2.4 mm (M)
SCW-2M2M060-S1DatasheetDC50175060"Semi-Rigid0.087"0.126"2.4 mm (M)
SCW-2M2M060-S1-PMDatasheetDC50175060"Semi-Rigid0.087"0.126"2.4 mm (M)
SCW-KMKM003-S1DatasheetDC4018503"Semi-Rigid0.087"0.126"K(M)
SCW-KMKM003-S1-PMDatasheetDC4018503"Semi-Rigid0.087"0.126"K(M)
SCW-KMKM006-S1DatasheetDC4018506"Semi-Rigid0.087"0.126"K(M)
SCW-KMKM006-S1-PMDatasheetDC4018506"Semi-Rigid0.087"0.126"K(M)
SCW-KMKM012-S1DatasheetDC40185012"Semi-Rigid0.087"0.126"K(M)
SCW-KMKM012-S1-PMDatasheetDC40185012"Semi-Rigid0.087"0.126"K(M)
SCW-KMKM024-S1DatasheetDC40185024"Semi-Rigid0.087"0.126"K(M)
SCW-KMKM024-S1-PMDatasheetDC40185024"Semi-Rigid0.087"0.126"K(M)
SCW-KMKM040-S1DatasheetDC40185040"Semi-Rigid0.087"0.126"K(M)
SCW-KMKM040-S1-PMDatasheetDC40185040"Semi-Rigid0.087"0.126"K(M)
SCW-KMKM048-S1DatasheetDC40185048"Semi-Rigid0.087"0.126"K(M)
SCW-KMKM048-S1-PMDatasheetDC40185048"Semi-Rigid0.087"0.126"K(M)
SCW-KMKM060-S1DatasheetDC40185060"Semi-Rigid0.087"0.126"K(M)
SCW-KMKM060-S1-PMDatasheetDC40185060"Semi-Rigid0.087"0.126"K(M)
SCW-SMSM003-S1DatasheetDC26.517503"Semi-Rigid0.087"0.126"SMA (M)
SCW-SMSM003-S1-PMDatasheetDC26.517503"Semi-Rigid0.087"0.126"SMA (M)
SCW-SMSM006-S1DatasheetDC26.517506"Semi-Rigid0.087"0.126"SMA (M)
SCW-SMSM006-S1-PMDatasheetDC26.517506"Semi-Rigid0.087"0.126"SMA (M)
SCW-SMSM012-S1DatasheetDC26.5175012"Semi-Rigid0.087"0.126"SMA (M)
SCW-SMSM012-S1-PMDatasheetDC26.5175012"Semi-Rigid0.087"0.126"SMA (M)
SCW-SMSM024-S1DatasheetDC26.5175024"Semi-Rigid0.087"0.126"SMA (M)
SCW-SMSM024-S1-PMDatasheetDC26.5175024"Semi-Rigid0.087"0.126"SMA (M)
SCW-SMSM040-S1DatasheetDC26.5175040"Semi-Rigid0.087"0.126"SMA (M)
SCW-SMSM040-S1-PMDatasheetDC26.5175040"Semi-Rigid0.087"0.126"SMA (M)
SCW-SMSM048-S1DatasheetDC26.5175048"Semi-Rigid0.087"0.126"SMA (M)
SCW-SMSM048-S1-PMDatasheetDC26.5175048"Semi-Rigid0.087"0.126"SMA (M)
SCW-SMSM060-S1DatasheetDC26.5175060"Semi-Rigid0.087"0.126"SMA (M)
SCW-SMSM060-S1-PMDatasheetDC26.5175060"Semi-Rigid0.087"0.126"SMA (M)
