Noise Sources

メーカー名:Eravant

製品仕様

Product Specifications

ModelData sheetMinimum Frequency [GHz]Maximum Frequency [GHz]ENR [dB]ENR Flatness [dB]Temperature Stability [dB/°C]Long Term Temperature Stability [dB/day]DC Bias [VDC/mA]RF Output
STZ-05-01Datasheet14022014±2.00.010.05+28 / 60WR-05 Waveguide
STZ-05-I1Datasheet14022012±2.00.010.05+28 / 60WR-05 Waveguide
STZ-06-01Datasheet11017013.5±2.50.010.05+28 / 60WR-06 Waveguide
STZ-06-I1Datasheet11017012±2.00.010.05+28 / 60WR-06 Waveguide
STZ-08-01Datasheet9014014±2.00.010.05+28 / 60WR-08 Waveguide
STZ-08-I1Datasheet9014012±2.00.010.05+28 / 60WR-08 Waveguide
STZ-10-01Datasheet7511014±1.50.010.05+28 / 60WR-10 Waveguide
STZ-10-I1Datasheet7511012±1.50.010.05+28 / 60WR-10 Waveguide
STZ-12-01Datasheet609015±1.50.010.05+28 / 60WR-12 Waveguide
STZ-12-I1Datasheet609013±1.50.010.05+28 / 60WR-12 Waveguide
STZ-15-01Datasheet507515±1.40.010.05+28 / 60WR-15 Waveguide
TZ-15-I1Datasheet507513.5±1.40.010.05+28 / 60WR-15 Waveguide
STZ-19-01Datasheet406014±1.50.010.05+28 / 60WR-19 Waveguide
STZ-19-I1Datasheet406013±1.50.010.05+28 / 60WR-19 Waveguide
STZ-22-01Datasheet335016±1.50.010.05+28 / 60WR-22 Waveguide
STZ-22-I1Datasheet335013±1.50.010.05+28 / 60WR-22 Waveguide
STZ-28-01Datasheet26.54016±1.00.010.05+28 / 60WR-28 Waveguide
STZ-28-I1Datasheet26.54015±1.00.010.05+28 / 60WR-28 Waveguide
STZ-60390320-12-I1Datasheet609020±1.50.010.05+28 / 75WR-12 Waveguide
STZ-60390322-12-01Datasheet609020±2.00.010.05+28 / 75WR-12 Waveguide
STZ-60396320-12-I1Datasheet609620±2.00.010.05+28 / 75WR-12 Waveguide
STZ-75311418-10-I1Datasheet7511018±1.50.010.05+28 / 60WR-10 Waveguide
STZ-75311420-10-01Datasheet7511020±1.50.010.05+28 / 60WR-10 Waveguide

備考

Remarks

お問い合わせからアフターフォローまで一貫して当社にお任せ下さい。
