Mechanical Tunable Phase Shifters

メーカー名:Eravant

製品仕様

Product Specifications

Model NumberData sheetMinimum FrequencyMaximum FrequencyInsertion LossPhase Shifting RangePower HandlingInput/Output
STP-18-06-M2Datasheet110 GHz170 GHz1.2 dB0 to 180°0.40 WWR-06 Waveguide
STP-18-28-M1Datasheet24 GHz44 GHz0.5 dB0 to 180°1.0 WWR-28 Waveguide
STP-18-28-M2Datasheet26.5 GHz40 GHz0.5 dB0 to 180°1.0 WWR-28 Waveguide
STP-18-22-M2Datasheet33 GHz50 GHz0.5 dB0 to 180°0.75 WWR-22 Waveguide
STP-18-19-M2Datasheet40 GHz60 GHz0.5 dB0 to 180°0.75 WWR-19 Waveguide
STP-18-15-M2Datasheet50 GHz75 GHz0.5 dB0 to 180°0.60 WWR-15 Waveguide
STP-18-12-M2Datasheet60 GHz90 GHz0.5 dB0 to 180°0.60 WWR-12 Waveguide
STP-18-10-M2Datasheet75 GHz110 GHz0.5 dB0 to 180°0.60 WWR-10 Waveguide
STP-18-08-M2Datasheet90 GHz140 GHz1.0 dB0 to 180°0.4 WWR-08 Waveguide

備考

Remarks
