Faraday Isolators

メーカー名:Eravant

製品仕様

Product Specifications

modelData sheetMinimum Frequency [GHz]Maximum Frequency [GHz]Insertion Loss [dB]Isolation [dB]Return Loss [dB]Power Handling [W]RF Port
STF-06-91-CDatasheet110180328140.8WR-06 Waveguide
STF-06-91Datasheet110170330140.8WR-06 Waveguide
STF-06-S1-CDatasheet110170328-0.8WR-06 Waveguide
STF-06-S1Datasheet110170330-0.8WR-06 Waveguide
STF-05-S1Datasheet140220420140.2WR-05 Waveguide
STF-05-S1-CDatasheet140220530150.1WR-05 Waveguide
STF-04-S1Datasheet170260430150.1WR-04 Waveguide
STF-42-S1Datasheet1826.51.230-2WR-42 Waveguide
STF-34-S1Datasheet22331.328141.8WR-34 Waveguide
STF-28-91Datasheet26.5401.230141.8WR-28 Waveguide
STF-28-S1Datasheet26.5401.230-1.8WR-28 Waveguide
STF-22-S1Datasheet33501.230-1.5WR-22 Waveguide
STF-3536031328-19-S1Datasheet35601.328151.5WR-19 Waveguide
STF-19-S1Datasheet40601.328-1.5WR-19 Waveguide
STF-19-91Datasheet40601.328141.5WR-19 Waveguide
STF-15-91-CDatasheet50751.528141.5WR-15 Waveguide
STF-15-91Datasheet50751.528-1WR-15 Waveguide
STF-15-S1-CDatasheet50751.528-1.5WR-15 Waveguide
STF-15-S1Datasheet50751.528-1.5WR-15 Waveguide
STF-12-91-CDatasheet60901.528141.2WR-12 Waveguide
STF-12-S1-RHDatasheet60901.528-1WR-12 Waveguide
STF-12-91Datasheet60901.528-1.2WR-12 Waveguide
STF-12-S1-CDatasheet60901.528-1.2WR-12 Waveguide
STF-12-S1Datasheet60901.528-1.2WR-12 Waveguide
STF-10-91-CDatasheet751101.528-1WR-10 Waveguide
STF-10-91Datasheet751101.528-1WR-10 Waveguide
STF-10-S1-CDatasheet751101.528-1WR-10 Waveguide
STF-10-S1Datasheet751101.528-1WR-10 Waveguide
STF-08-91-CDatasheet90140228-0.8WR-08 Waveguide
STF-08-S1-CDatasheet90140228-0.8WR-08 Waveguide
STF-08-S1Datasheet90140230-1WR-08 Waveguide
STF-08-91Datasheet90140230141WR-08 Waveguide
