Dual-Directional Waveguide Directional Couplers

メーカー名:Eravant

製品仕様

Product Specifications

ModelData sheetMinimum Frequency [GHz]Maximum Frequency [GHz]Insertion Loss [dB]Coupling [dB]Directivity [dB]VSWRCoupler TypeRF Ports
SWD-1040H-10-DBDatasheet75110110401.1:14-Port Dual-directional, Split-blockWR-10 WG
SWD-2040H-10-DBDatasheet75110120401.1:14-Port Dual-directional, Split-blockWR-10 WG
SWD-0340H-12-DBDatasheet60901.534020 dB4-Port Dual-directional, Split-blockWR-12 WG
SWD-0640H-12-DBDatasheet60901.56401.1:14-Port Dual-directional, Split-blockWR-12 WG
SWD-1040H-12-DBDatasheet60901.5104020 dB4-Port Dual-directional, Split-blockWR-12 WG
SWD-2040H-12-DBDatasheet60901.5204020 dB4-Port Dual-directional, Split-blockWR-12 WG
SWD-3040H-12-DBDatasheet60901.5304020 dB4-Port Dual-directional, Split-blockWR-12 WG
SWD-4040H-12-DBDatasheet60901.5404020 dB4-Port Dual-directional, Split-blockWR-12 WG
SWD-2040H-15-DBDatasheet50751.120401.1:14-Port Dual-directional, Split-blockWR-15 WG

備考

Remarks
