DC Blocks

メーカー名:Eravant

製品仕様

Product Specifications

ModelData sheetMinimum Frequency [MHz]Maximum Frequency [GHz]Return Loss [dB]Insertion Loss [dB]Impedance [Ohms]Connector 1Connector 2
SCB-016-VFVM-U2Datasheet1067151501.85 mm Female1.85 mm Male
SCB-050-2F2M-U2Datasheet1050151502.4 mm Female2.4 mm Male
SCB-050-KFKM-U2Datasheet1040151502.92 mm Female2.92 mm Male
SCB-050-KFKM-U6Datasheet3040210.6502.92 mm Female2.92 mm Male
SCB-050-3F3M-U2Datasheet4526.5171503.5 mm Female3.5 mm Male
SCB-050-3F3M-U6Datasheet3026.5220.6503.5 mm Female3.5 mm Male

備考

Remarks
