Compact Fixed Attenuators

メーカー名:Eravant

製品仕様

Product Specifications

ModelData sheetMinimum Frequency [GHz]Maximum Frequency [GHz]AttenuationReturn Loss [dB]Power Handling [W]RF PortAttenuator Type
STA-03-10-F1-C-1.2Datasheet751103 dB @ 92.5 GHz200.5WR-10 WaveguideFixed
STA-06-10-F1-C-1.2Datasheet751106 dB @ 92.5 GHz200.5WR-10 WaveguideFixed
STA-10-10-F1-C-1.2Datasheet7511010 dB @ 92.5 GHz200.5WR-10 WaveguideFixed
STA-20-10-F1-C-1.2Datasheet7511020 dB @ 92.5 GHz200.5WR-10 WaveguideFixed
STA-30-10-F1-C-1.2Datasheet7511030 dB @ 92.5 GHz200.5WR-10 WaveguideFixed
STA-03-12-F1-C-1.2Datasheet60903 dB @ 75 GHz200.5WR-12 WaveguideFixed
STA-06-12-F1-C-1.2Datasheet60906 dB @ 75 GHz200.5WR-12 WaveguideFixed
STA-10-12-F1-C-1.2Datasheet609010 dB @ 75 GHz200.5WR-12 WaveguideFixed
STA-20-12-F1-C-1.2Datasheet609020 dB @ 75 GHz200.5WR-12 WaveguideFixed
STA-30-12-F1-C-1.2Datasheet609030 dB @ 75 GHz200.5WR-12 WaveguideFixed
STA-03-15-F1-C-1.2Datasheet50753 dB @ 62.5 GHz200.5WR-15 WaveguideFixed
STA-06-15-F1-C-1.2Datasheet50756 dB @ 62.5 GHz200.5WR-15 WaveguideFixed
STA-10-15-F1-C-1.2Datasheet507510 dB @ 62.5 GHz200.5WR-15 WaveguideFixed
STA-20-15-F1-C-1.2Datasheet507520 dB @ 62.5 GHz200.5WR-15 WaveguideFixed
STA-30-15-F1-C-1.2Datasheet507530 dB @ 62.5 GHz200.5WR-15 WaveguideFixed

備考

Remarks
