Bulkhead Coaxial Adapters

メーカー名: Eravant

製品仕様

Product Specifications

Model NumberData sheetMinimum FrequencyMaximum FrequencyInsertion LossReturn LossImpedanceConnector 1Connector 2
SCT-SFSF-U8-BDatasheetDC26.5 GHz0.3 dB20 dB50 OhmsSMA FemaleSMA Female
SCT-KFKF-U8-BDatasheetDC40 GHz0.4 dB20 dB50 Ohms2.92 mm Female2.92 mm Female
SCT-2F2F-U8-BDatasheetDC50 GHz0.4 dB20 dB50 Ohms2.4 mm Female2.4 mm Female
SCT-VFVF-U8-BDatasheetDC67 GHz0.5 dB17 dB50 Ohms1.85 mm Female1.85 mm Female

備考

Remarks
