Broadband Amplifiers

メーカー名:Eravant

製品仕様

Product Specifications

ModelData sheetMinimum Frequency [GHz]Maximum Frequency [GHz]Gain [dB]P1dB [dBm]Psat [dBm]Input Return Loss [dB]Output Return Loss [dB]DC Bias [VDC/mA]RF Input/Output
SBB-0126533015-VFVF-S1Datasheet0.16530+15+1888+12/600V (F)
SBB-0115034018-2F2F-E3Datasheet0.015040+18+2088+12/6502.4 mm (F)
SBB-0115033218-2F2F-E3Datasheet0.015032+18+191010+12/4502.4 mm (F)
SBB-0524034318-KFKF-E8Datasheet0.54043+18+191010+12/650K (F)
SBB-0524034018-KFKF-E3Datasheet0.54040+18+191010+12/6502.92 mm (F)
SBB-0524032818-KFKF-E3Datasheet0.54028+18+191010+12/6502.92 mm (F)
SBB-0524031818-KFKF-E3Datasheet0.54018+18+191010+12/2502.92 mm (F)
SBB-1834232815-KFKF-E3Datasheet184228+15+161010+5/240K (F)
SBB-1834034018-2F2F-E3Datasheet184040+18+191010+12/6502.4 mm (F)
SBB-1834034018-KFKF-E3Datasheet184040+18+191010+12/650K (F)
SBB-1834033525-KFKF-E3Datasheet184035+24+251010+12/900K (F)
SBB-1834033022-2F2F-E3Datasheet184030+22+231010+12/5502.4 mm (F)
SBB-1834033022-KFKF-E3Datasheet184030+22+231010+12/550K (F)
SBB-0123031520-KFKF-S1Datasheet0.13015+20+2166+8/160K (F)
SBB-0123031516-KFKF-E3Datasheet0.13015+16+1766+12/160K (F)
SBB-0122733808-KFKF-E3Datasheet0.126.538+12+1488+8/500K (F)
SBB-0522432617-KFKF-S1Datasheet0.52426+17+181010+8/400K (F)
SBB-0122233530-SFSF-E3Datasheet0.12235+30+321010+15/800SMA (F)
SBB-0112034014-SFSF-E3Datasheet0.012040+14+151212+12/650SMA (F)
