Bias Tees

メーカー名:Eravant

製品仕様

Product Specifications

ModelData sheetMinimum Frequency [GHz]Maximum Frequency [GHz]Insertion Loss [dB]Return Loss [dB]DC Voltage [VDC]DC Current [mA]Power Handling [W]Input PortOutput PortDC Port
SCV-000853402505-VFVF-U3Datasheet308547+2550011.85 mm Female1.85 mm FemaleSMA Female
SCV-000723402505-VFVF-U3Datasheet307247+2550011.85 mm Female1.85 mm FemaleSMA Female
SCV-000653402505-VFVF-U3Datasheet306548+2550011.85 mm Female1.85 mm FemaleSMA Female
SCV-000403302508-KFKF-U3Datasheet3040310+2575012.92 mm Female2.92 mm FemaleSMA Female
SCV-000273223008-KFKF-U3Datasheet30272.210+2575012.92 mm Female2.92 mm FemaleSMA Female
SCV-000183202505-SFSF-U3Datasheet0.1 MHz18212+505001SMA FemaleSMA FemaleSMA Female

備考

Remarks

お問い合わせからアフターフォローまで一貫して当社にお任せ下さい。
