Balanced Upconverters

メーカー名:Eravant

製品仕様

Product Specifications

Model NumberData sheetMinimum RF FrequencyMaximum RF FrequencyMinimum LO FrequencyMaximum LO FrequencyMinimum IF FrequencyMaximum IF FrequencyLO Pumping PowerConversion LossRF Port
SFU-06-N1Datasheet110 GHz170 GHz110 GHz170 GHzDC40 GHz+13 dBm13 dBWR-06 Waveguide
SFU-42-N1Datasheet18 GHz26.5 GHz18 GHz26.5 GHzDC8.5 GHz+13 dBm6 dBWR-42 Waveguide
SFU-28-N1Datasheet26.5 GHz40 GHz26.5 GHz40 GHzDC13.5 GHz+13 dBm7.5 dBWR-28 Waveguide
SFU-22-N1Datasheet33 GHz50 GHz33 GHz50 GHzDC17 GHz+13 dBm7 dBWR-22 Waveguide
SFU-19-N1Datasheet40 GHz60 GHz40 GHz60 GHzDC20 GHz+13 dBm8 dBWR-19 Waveguide
SFU-19-E2Datasheet40 GHz60 GHz40 GHz60 GHzDC20 GHz+3 dBm8 dBWR-19 Waveguide
SFU-15-N1Datasheet50 GHz75 GHz50 GHz75 GHzDC25 GHz+13 dBm9 dBWR-15 Waveguide
SFU-15-N1-ADatasheet50 GHz75 GHz50 GHz75 GHzDC25 GHz+13 dBm9 dBWR-15 Waveguide
SFU-15-E2Datasheet50 GHz75 GHz50 GHz75 GHzDC25 GHz+3 dBm9 dBWR-15 Waveguide
SFU-12-N1Datasheet60 GHz90 GHz60 GHz90 GHzDC30 GHz+13 dBm9 dBWR-12 Waveguide
SFU-12-E2Datasheet60 GHz90 GHz60 GHz90 GHzDC30 GHz+3 dBm9 dBWR-12 Waveguide
SFU-10-N1Datasheet75 GHz110 GHz75 GHz110 GHzDC35 GHz+13 dBm9.5 dBWR-10 Waveguide
SFU-10-E2Datasheet75 GHz110 GHz75 GHz110 GHzDC35 GHz+3 dBm10 dBWR-10 Waveguide
SFU-08-E2Datasheet90 GHz140 GHz90 GHz140 GHzDC20 GHz+3 dBm13 dBWR-08 Waveguide
SFU-08-N1Datasheet90 GHz140 GHz90 GHz140 GHzDC40 GHz+13 dBm9 dBWR-08 Waveguide

備考

Remarks
