概要

広帯域、低雑音指数〔Broad-Band, Low Noise Figure〕

GaAs FET / pHEMTのRF特性(25°Cでの標準的な性能)

  • ウルトラリニア、ハイダイナミックレンジ、低位相ノイズ
    Ultra Linear, High Dynamic Range, Low Phase Noise
  • GaAsプロセスは、実証済みの信頼性を備えた宇宙用途に承認されています
    GaAs Process is Approved for Space Applications with Proven Reliability
  • コマーシャル、インダストリアル、ミリタリー、スペースグレード
    Commercial, Industrial, Military, and Space Grade
  • MIL-PRF-38534に基づく評価での100%ウェーハボンドプル、ダイシア、ウェーハDCバーンイン、およびベークテスト
    100% Wafer Bond Pull, Die Shear, Wafer DC Burn In, and Bake Tests in Evaluation per MIL-PRF-38534
  • 出荷用にデータが記録された100%ダイプローブテスト
    100% Die Probe Test with Data Recorded for Shipment
  • 出荷前に100%視覚的パフォーマンス(レベル1、3、または4)
    100% Visual Performed (Level 1, 3, or 4) before Shipment
  • 100%Idss一致でパフォーマンスの一貫性を提供
    100% Idss Match to Provide Performance Consistency
  • ご要望に応じてRFサンプルテスト機能をご用意
    RF Sample Test Capability Available Upon Request
  • 標準およびカスタムデバイス仕様
    Standard and Custom Device Specifications
  • 利用可能なハイレルおよびスペースレルスクリーニングオプション
    High-Rel and Space-Rel Screening Options Available
  • RoHS(鉛フリー)対応品あり
    RoHS (lead-free) Compliant Product Available



仕様

ModelData sheetPackage Available Sealed / HermeticGate Width / Length umGate Layout MethodGate Drain Source Bond Pads QtyChip Thick-ness & VIA Hole mil, y/nS.S. Gain @12GHz Typ/Min dBN.F. @12Ghz Typ/Max dBGa @ N.F @12GHz Typ/Min dBP-1dB @12GHz Typ/Min dBm
MwT-4Datasheet70, 73 / NA180/0.3single stripe1, 1, 25, no9.0 / 8.01.5 / 1.89.0 / 8.014.0/13.0
MwT-7
*1
Nonlinear Model
Datasheet70, 73 / NA250/0.3single stripe2, 2, 25, no10.5 / 10.02.0 / -8.0 / -20.0/18.0
MwT-LP7
*1
Datasheet70, 73 / NA250/0.3single stripe2, 2, 25, no10.5 / 10.02.0 / -8.0 / -20.0/18.0
MwT-7FDatasheet70, 73 / NA250/0.3single stripe2, 2, 25, no10.5 / 10.02.0 / -8.0 / -20.0/18.0
MwT-9/A9
*2
84, 70, 73 / 71750/0.3single stripe1, 1, 25, no9.5 / 8.51.8 / -6.5 / 6.025.5/23.0
MwT-9FDatasheet84, 70, 73 / 71750/0.3single stripe1, 1, 25, no9.5 / 8.51.8 / -6.5 / 6.025.5/23.0
MwT-A989Datasheetsot89750/0.5Interdigit1, 1, 24, no17.0/15.0
(1)
0.9
(1)
25.0/23.0
MwT-A989SBDatasheetsot89750/0.5Interdigit1, 1, 24, no17.0/15.0
(1)
0.9
(1)
25.0/23.0

備考

*1) MwT-7F will soon replace MwT-7 and MwT-LP7.
*2) MwT-9F will soon replace MwT-9 and MwT-A9.

SB = Self-Biased
(1) @ 2.0GHz
