WiMAX用GaNパワー・アンプ
取扱いメーカー
すぐお見積りいたします
仕様
| Model | Data sheet | Case Code Sealed QFN | Freq Range [GHz] | Linear Gain Typ/Min [dB] | Gain ± Flatness Typ/Max [dB] | Input Return Loss Typ [dB] | Output Return Loss Typ [dB] | P3dB Typ [dBm] | Pout @ 2.5% EVM Typ [dBm] | IP3 Typ [dBm] | DC Current Typ/Max [mA] |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MGA-242740-02 |  | 2 | 2.4-2.7 | 15.0 / 12.0 | 1.0 / 1.5 | 8 | 8 | 40 | 33 | 40 | 50 /400 |
| MGA-333840-02 | | 2 | 3.3-3.8 | 12.0 / 10.0 | 1.0 / 1.5 | 8 | 8 | 40 | 33 | 40 | 100 / 400 |
| MGA-444940-02 | | 2 | 4.4-4.9 | 12.0 / 10.0 | 1.0 / 1.5 | 8 | 10 | 40 | 33 | 40 | 100 / 400 |
| MGA-445343-99 | | 99 | 4.4-5.3 | 14.0 / 12.0 | 1.0 / 1.5 | 7 | 4 | 43 | 35 | - | 150 / 300 |
| MGA-445940-02 | | 02 | 4.4-5.9 | 14.0 / 13.0 | 0.6 / 1.0 | 6 | 3 | 40 | 34 | 40 | 100 / 1200 |
| MGA-495940-02 | | 2 | 4.9-5.9 | 12.0 / 10.0 | 1.0 / 1.5 | 8 | 8 | 40 | 33 | 40 | 100 / 400 |
| MGA-515844-99 | | 99 | 5.1-5.8 | 16 | 1 | 10 | 12 | 44 | 35 | - | >2000 |
| MGA-718540-HP3 | | - | 7.1-8.5 | 14.0 / 12.0 | 1.0 / 1.5 | 10 | 7 | 42 | - | - | - |
| MGA-718544-HP3 | | - | 7.1-8.5 | 13.5 / 11.0 | 1.0 / 1.5 | 4.5 | 6 | 44 | - | - | - |
